    Silicone self fusing tape, insulation & fireproof for large cables and irregular shape conductor

    Ask Lasest Price
    Brand Name : ZKCS
    Model Number : EPR-5005/8/3
    Certification : ROSH 2.0
    Supply Ability : 5000pes/month
    Delivery Time : 20-30days
    • Product Details
    • Company Profile

    Silicone self fusing tape, insulation & fireproof for large cables and irregular shape conductor

    Silicone self fusing tape, insulation & fireproof for large cables and irregular shape conductor


    Description:


    Self-Fusing Silicone Rubber Electrical Tape 70 is a high-temperature arc and track-resistant tape composed of self-fusing, inorganic silicone rubber with easy-tear and easy-strip liner.


    Features:

    1: Have good fire performance, can achieve UL94-V0 flame retardant standard

    2: Excellent arc force resistance characteristics

    3: Excellent resistance to power leakage tracking features

    4: Excellent Ozone resistance characteristics

    5: Excellent insulation properties

    6: Good sticker make installation easier

    7: Can use for a long time in very low temperature, nice low temperature resistance performance

    8: Good heat resistance characteristics, can be used in 180℃ for long time use.

    9: Excellent weather resistance properties


    Application:

    1. It can be applied to high-voltage cable heads to play a good role in anti-arc and anti-leakage tracking. It is suitable for wrapping on power cables of various insulation materials.

    2. It can be used for insulation protection in electrical cabinets.

    3. It can be applied to H-class heat-resistant insulation.


    ProductModel No.Normal Specification
    Silicone Self Fusing TapeZKST-500550mm*0.5mm*5m
    ZKST-500850mm*0.8mm*5m
    ZKST-250325mm*0.3mm*5m
    ZKST-250525mm*0.5mm*5m
    ZKST-250825mm*0.8mm*5m
    ZKST-2508B38mm*0.8mm*4.5m

    Technical Parameters:


    No.ItemsTest standardUnitResults
    1HardnessGB/T 531.1-2008Shores A50±10
    2Tensile strengthGB/T 528-2009Mpa≥4.5
    3Elongation at breakGB/T 528-2009%≥350
    4Dielectric coefficientGB/T1408.1-2006KV/mm≥22
    5Volume resistivityGB/T1410-2006Ω.cm≥1.3*1015
    6Self-adhesiveASTM D2148N/cm>3.5
    7Water absorption%<0.9
    8densityGB/T 20631.2g/cm3<1.5
    9Flame retardantgradeUL-94V0
    10Heat resistant temperature180
    11Withstand voltage15KV
    12ColorRed, yellow, green etc
